Technical parameters:

Model: Jhon - 005

The input voltage: AC110-260 - v 50/60 hz

Rated power: 140 w / 350 w

Light specifications: 1 w / 3 w

Lamp bead amount: 108 (28 b + 24 r + g + 28 28 w)

Service life: 50000 hours

The control channel: 14 DMX channels

Ngan: color RGBW linear mixed color

Color temperature: 0-100% linear adjustment

Dimming: 0-100% linear adjustment

Stroboscopic: 1 ~ 25 times per second

Rotation Angle: horizontal / 540 ° 540 °, 270 ° vertically;

With the function of automatic return

Beam Angle: the factory default 15 °, and it is optional.

Control mode: international standard DMX512 signal, master-slave synchronous control mode,

Stand-alone mode. Self-inspection mode

Other features: horizontal, vertical speed is adjustable

LCD screen brightness and contrast is adjustable

Protection grade: high temperature resistant engineering plastic + die-casting aluminum, IP20

Ambient temperature: - 20 ° ~ 40 °

11 kg weight:
